WellFusion™ Elite 180K - Commercial Well Iron Breaker

The Invisible Problem

Iron contamination in commercial water systems operates differently than residential exposure. At higher flow rates and continuous demand cycles, even moderate iron concentrations accumulate rapidly inside plumbing, valves, and equipment. What begins as faint discoloration quickly becomes permanent staining across restrooms, kitchens, and laundry facilities. Fixtures develop rust-colored deposits that resist commercial cleaners. Water heaters fill with sediment that reduces thermal efficiency and shortens service intervals. Dishwashers, ice machines, and coffee equipment suffer accelerated wear as iron particles pass through screens, seals, and spray arms.

When iron levels exceed two parts per million, standard filtration cannot keep pace with oxidation. The mineral load overwhelms media beds designed for lighter contamination, causing fouling, channeling, and breakthrough. Without intervention, every cycle draws iron deeper into distribution systems. Stains harden. Flow restrictions develop. Maintenance costs rise. For commercial operations drawing from wells or iron-rich municipal supplies, specialized treatment is not optional, it is foundational to operational integrity. To better understand how targeted media addresses contamination at scale, explore the broader category of iron removal systems designed for oxidation and filtration before damage occurs.

The Certified Solution

The WellFusion™ Elite 180K employs Aldex C-800 10% crosslinked resin, a high-capacity ion exchange media engineered specifically for removing dissolved iron, manganese, and low-level hardness in commercial environments. With a 180,000-grain capacity and 6 cubic feet of resin housed in a 16" × 65" mineral tank, this system supports facilities up to 6,500 square feet with flow rates reaching 40 gallons per minute. The Clack WS2 2-inch control valve delivers precise regeneration cycles calibrated to restore media capacity without wasting water or salt.

Built at our Florida facility with components meeting NSF/ANSI 44 and 372 standards, every valve, fitting, and resin charge is inspected before shipment. The crosslinked resin structure resists fouling and maintains uniform bead integrity across thousands of service cycles. Backwash intervals flush captured iron and regenerate active exchange sites automatically, eliminating manual intervention and maintaining consistent treatment capacity. The high-flow valve system ensures even pressure distribution during service and complete media regeneration during backwash, preventing channeling and extending media life.

Chemical-free oxidation and filtration reduce both maintenance complexity and ongoing costs. The system is designed for ten to fifteen years of service life when operated within recommended parameters and maintained per published schedules. For facilities where iron contamination appears alongside hydrogen sulfide, consider how sulfur removal systems provide coordinated treatment when odor and staining occur together in commercial water supplies.

Pure Water Living

After installation, water clarity improves within the first regeneration cycle. Restrooms and kitchens that once required daily attention stay cleaner across weekly maintenance intervals. Laundry emerges without orange discoloration. Drinking fountains and ice machines deliver water without metallic edge. Water heaters operate at rated efficiency without iron sediment accumulating at tank bottoms. Equipment operates as engineered. Downtime decreases. Staff confidence in facility water returns. This is whole-facility protection designed for real-world commercial conditions. Operators discover that fixtures maintain original finish, whites stay white, and equipment replacement intervals extend naturally when iron no longer infiltrates daily operations. Guest satisfaction improves. Cleaning protocols simplify. Maintenance budgets stabilize. Pure Water. Pure Trust.

Performance

• Ideal For: Commercial/Industrial
• System Capacity: 180,000 Grains
• Occupants: Commercial
• Household Size: Up to ~6,500 sq ft
• Number of Bathrooms: Commercial
• Media Volume: 6 Cu.Ft
• Media Type: Water Softener - Aldex C-800 10% Crosslinked Resin
• Service Life: ~ 10-15 years
• Max Flow Rate: 40 gpm
• Backwash: 8-9 gpm

Technical Specifications

• Valve: Clack WS2 (2")
• Input & Output Line Size: 2” NPT
• Tank Dimensions: 16"x65"
• Product Dimensions: 16"L × 16"W × 72"H
• Product Weight: 416 lb, 189 kg
• Power Requirement: 110V Standard (Plug-In Transformer Included)
• Bypass Valve Included: Yes
• Operating Pressures: Requires 20–80 psi supply pressure
• Drain Line: 1.5” Female NPT

Additional Components

• 1/2" Dia drain line tube 10' in length

Installation Time & Requirements

• Installation Type: Whole-House Point of Entry
• Estimated Installation Time: A professional water softener installation typically takes 8 to 16 hours, but this can vary depending on the complexity of the job and the type of system.

Commercial Systems – Production & Delivery Timeline

AQUALIVIA™ commercial systems are engineered based on project requirements. Many of these systems are custom-built, tested, and configured to ensure optimal performance for your specific application.

• Standard commercial configurations typically require 2 to 4 weeks for production

• Custom-engineered or large-scale systems may require up to 90 days depending on specifications, components, and current production schedule

• Orders placed after 12:00 PM ET begin processing the next business day

Order Updates & Communication

After your order is placed, the AQUALIVIA™ team will personally contact you to confirm all specifications.

Throughout the process, you will receive ongoing updates, including production status, testing progress, and estimated shipping readiness. Our goal is full transparency so you always know exactly where your project stands.

We build every system with precision and care, and while timelines may vary, we always aim to complete and deliver your system as efficiently as possible without compromising quality.

Estimated Transit Times (After Shipment)

• Ground Freight: 5 to 10 business days

• Pallet Freight (Large Systems): 5 to 10 business days

Freight Delivery

Large commercial systems are shipped via pallet freight. An adult must be present at delivery to inspect and sign for the shipment.

Inspection

Please inspect your system upon delivery and report any damage within 3 business days.

Optional Professional Installation

AQUALIVIA™ offers optional on-site installation for commercial systems.

If you would like our team to install the system at your facility, please contact us at:

info@AQUALIVIA.com

to request a custom installation quote.

International Orders

International shipping is available. Duties and taxes are the responsibility of the customer. All international sales are final unless covered under warranty.

Warranty:

At AQUALIVIA™, we stand behind the quality of our water treatment systems. Every product is carefully built to last, and we’re proud to offer strong warranty coverage to give you peace of mind.

What’s Covered

• Mineral Tanks: 10 years (up to 13" × 54"), 5 years for larger tanks.
• Control Valves: 5 years.
• Brine Tanks: 5 years.
• Accessories & Components: 1 year.
• AQUAREX™ Whole House Filter: 5 years.
• OZONEX™ Ozone Systems: 1 year.
• AquaVRay™ UV Systems: 1 year.
• HydroClear™: 1 year(system only)
• AquaRevive™ RO Systems: 1 year(system only)

What’s Not Covered

• Regular-use consumables (filters, resins, membranes, UV lamps, cartridges).
• Damage caused by misuse, freezing, flooding, power surges, or improper installation.
• Products used with non-AQUALIVIA™ parts or outside normal water conditions.

Our Promise

We’ll repair, replace, or provide a comparable solution if your system has a covered defect. Our goal is to make sure your AQUALIVIA™ system works the way it should, so you can enjoy clean, pure water with confidence.

👉 For warranty support, please contact Info@AquaLivia.com.

Maintenance Requirement:
