WellFusion™ Elite 240K - Commercial Well Iron Breaker

The Invisible Problem

In commercial and large residential environments, iron contamination operates at a different scale. What begins as trace amounts in groundwater quickly becomes visible damage across dozens of fixtures, appliances, and high-use plumbing systems. With 240,000 grains of capacity and 8 cubic feet of specialized media, iron enters the building continuously, oxidizing inside pipes, water heaters, commercial dishwashers, laundry equipment, and HVAC systems. Orange and brown stains appear on every surface iron-rich water contacts. Equipment efficiency drops as sediment accumulates. Maintenance intervals shorten. Downtime increases.

At higher flow rates and usage volumes, even small concentrations of dissolved iron cause disproportionate damage. Multi-unit buildings, hospitality properties, food service operations, and large homes experience compounding effects. Guests notice staining. Appliances require earlier replacement. Energy costs rise as scale-insulated heating elements work harder. Without commercial-grade treatment, the cost of iron contamination grows exponentially with building size and occupancy. For facilities managing well water at this scale, understanding how iron removal systems integrate into commercial infrastructure is essential to protecting long-term investment and operational reliability.

The Certified Solution

The WellFusion™ Elite 240K employs 8 cubic feet of advanced ion exchange resin housed in an 18" × 65" mineral tank, engineered to handle dissolved iron, manganese, and hydrogen sulfide at commercial flow rates up to 60 gallons per minute. The Aldex C-800 10% cross-linked resin provides superior capacity and durability under continuous operation, while the Clack WS2 (2-inch) control valve ensures high-efficiency backwash cycles calibrated for heavy-duty service.

Every component is manufactured in the USA and tested at our Florida facility before shipment. The system meets NSF/ANSI 44 and NSF/ANSI Standard 372 certifications, ensuring compliance with lead-free plumbing regulations and performance standards required for commercial applications. The oversized valve and 2-inch NPT input and output lines support sustained flow without pressure loss, while the high-capacity resin bed maintains treatment effectiveness across extended service cycles. Backwash requires approximately 11 to 12 gallons per minute and operates automatically on a programmed schedule, regenerating the media bed and flushing captured contaminants without manual intervention.

The system operates within 20 to 125 psi supply pressure and temperatures ranging from 40° to 110°F, making it adaptable to diverse installation environments. With a service life of 10 to 15 years when properly maintained, the WellFusion™ Elite 240K provides long-term protection for commercial plumbing systems, appliances, and water-dependent equipment. When iron contamination appears alongside sulfur odor in well water, explore how coordinated sulfur removal systems address both contaminants simultaneously for complete treatment.

Pure Water Living

After installation, water quality transforms across the entire facility. Fixtures that required daily cleaning stay cleaner for weeks. Commercial laundry emerges without discoloration. Dishwashers operate without spotting glassware. Water heaters maintain efficiency without iron sediment fouling tanks and elements. Maintenance teams spend less time scrubbing stains and more time on productive tasks. Equipment operates as engineered, extending replacement intervals and reducing operational costs. Confidence in building water quality returns, whether serving residents, guests, or customers. Showers deliver consistent comfort. Coffee and beverage equipment produce better-tasting results. Ice machines generate clear, odor-free ice. The difference is measurable in every use, every day. Pure Water. Pure Trust.

Performance

• Ideal For: Commercial/Industrial
• System Capacity: 240,000 Grains
• Occupants: Commercial
• Household Size: Up to ~8,000 sq ft
• Number of Bathrooms: Commercial
• Media Volume: 8 Cu.Ft
• Media Type: Water Softener - Aldex C-800 10% Crosslinked Resin
• Service Life: ~ 10-15 years
• Max Flow Rate: 60 gpm
• Backwash: ~11–12 gpm

Technical Specifications

• Valve: Clack WS2 (2")
• Input & Output Line Size: 2” NPT
• Tank Dimensions: 18"x65"
• Product Dimensions: 18"L × 18"W × 73"H
• Product Weight: 556 lb, 253 kg
• Power Requirement: 110V Standard (Plug-In Transformer Included)
• Bypass Valve Included: Yes
• Operating Pressures: Requires 20–80 psi supply pressure
• Drain Line: 1.5” Female NPT

Additional Components

• 1/2" Dia drain line tube 10' in length

Installation Time & Requirements

• Installation Type: Whole-House Point of Entry
• Estimated Installation Time: A professional water softener installation typically takes 8 to 16 hours, but this can vary depending on the complexity of the job and the type of system.

Commercial Systems – Production & Delivery Timeline

AQUALIVIA™ commercial systems are engineered based on project requirements. Many of these systems are custom-built, tested, and configured to ensure optimal performance for your specific application.

• Standard commercial configurations typically require 2 to 4 weeks for production

• Custom-engineered or large-scale systems may require up to 90 days depending on specifications, components, and current production schedule

• Orders placed after 12:00 PM ET begin processing the next business day

Order Updates & Communication

After your order is placed, the AQUALIVIA™ team will personally contact you to confirm all specifications.

Throughout the process, you will receive ongoing updates, including production status, testing progress, and estimated shipping readiness. Our goal is full transparency so you always know exactly where your project stands.

We build every system with precision and care, and while timelines may vary, we always aim to complete and deliver your system as efficiently as possible without compromising quality.

Estimated Transit Times (After Shipment)

• Ground Freight: 5 to 10 business days

• Pallet Freight (Large Systems): 5 to 10 business days

Freight Delivery

Large commercial systems are shipped via pallet freight. An adult must be present at delivery to inspect and sign for the shipment.

Inspection

Please inspect your system upon delivery and report any damage within 3 business days.

Optional Professional Installation

AQUALIVIA™ offers optional on-site installation for commercial systems.

If you would like our team to install the system at your facility, please contact us at:

info@AQUALIVIA.com

to request a custom installation quote.

International Orders

International shipping is available. Duties and taxes are the responsibility of the customer. All international sales are final unless covered under warranty.

Warranty:

At AQUALIVIA™, we stand behind the quality of our water treatment systems. Every product is carefully built to last, and we’re proud to offer strong warranty coverage to give you peace of mind.

What’s Covered

• Mineral Tanks: 10 years (up to 13" × 54"), 5 years for larger tanks.
• Control Valves: 5 years.
• Brine Tanks: 5 years.
• Accessories & Components: 1 year.
• AQUAREX™ Whole House Filter: 5 years.
• OZONEX™ Ozone Systems: 1 year.
• AquaVRay™ UV Systems: 1 year.
• HydroClear™: 1 year(system only)
• AquaRevive™ RO Systems: 1 year(system only)

What’s Not Covered

• Regular-use consumables (filters, resins, membranes, UV lamps, cartridges).
• Damage caused by misuse, freezing, flooding, power surges, or improper installation.
• Products used with non-AQUALIVIA™ parts or outside normal water conditions.

Our Promise

We’ll repair, replace, or provide a comparable solution if your system has a covered defect. Our goal is to make sure your AQUALIVIA™ system works the way it should, so you can enjoy clean, pure water with confidence.

👉 For warranty support, please contact Info@AquaLivia.com.

Maintenance Requirement:
